Supply plastic cup (box) sealing machine

Main technical parameters of equipment

Technical parameter:

Model

Throughput

Filling volume

pressure

Voltage

LxWxHcm

weight

Model

Capacity (pcs/h)

Range Filling (ML)

Pressure Air

Voltage

Dimension (mm)

Weight (Kg)

LW-TF-2

1500-2500

30-1000

0.6-0.8Mpa

380V/50Hz

4000 * 850 * 1500

Seven hundred

LW-TF-4

3200-4200

30-1000

0.6-0.8Mpa

380V/50Hz

4000 * 850 * 1500

Nine hundred and fifty

LW-TF-6

4800-6300

30-1000

0.6-0.8Mpa

380V/50Hz

4000 * 850 * 1500

One thousand and two hundred

LW-TF-8

6400-8400

30-500

0.6-0.8Mpa

380V/50Hz

4000 * 850 * 1500

One thousand and five hundred

Two, equipment introduction

LW-TF equipment safety, high efficiency and stability, in accordance with CE, GMP specification.

Operator friendly interface, easy to set up, the main features are: product count, output settings, parameter memory, equipment status monitoring, equipment failure automatic shutdown, alarm tips fault location and help information.

1 process flow

Drop cup, filling, sealing cup, two seal, finished product

2 characteristic description

The equipment provided is a brand new, advanced and reliable product, which meets the requirements of the process. The plastic cup filling and sealing machine meets the following basic requirements in normal feeding and discharging:

1, the application object: the equipment used for the production of plastic cup fruit powder, Party A shall provide the pre delivery test machine and plastic cup sealing film, design B mold according to equipment provided by party a plastic cup and a sealing film for the standard.

2, basic functions: with automatic drop cup function, filling function heating, sealing (2 pressing) function, the gate film on the cursor function, automatic cutting film, automatic discharge function, automatic roll waste film function.

3, as the filling material for solid, solid filling accuracy; according to the requirements of the process can be adjusted.

4, the quality of work through the equipment after sealing products and plastic cup cover film to pressure evenly, pressing the premises can bear the pulling force is slightly less than the cover film can bear the tension by the processing equipment after sealing products passing rate of not less than 99%.

5, the composition of the brand: the manufacturer of equipment for the Party B company.

6, constitute the mechanical components of the material: stainless steel SUS304 material.

Equipment adaptability to the environment: the equipment can not be directly washed with water, to adapt to the environment temperature of 10 degrees -50 degrees Celsius, to adapt to the environmental humidity of 60%, in the above conditions can work without stopping.

Three, configuration

1, steel frame: paint outsourcing SUS304 stainless steel

2, mechanical components: SUS304 stainless steel rack

3, template mold: aluminum alloy frame

4, electrical components: Japan OMRON/ France TE

5, pneumatic components: Taiwan AIRTAC

6, optoelectronic components: Germany SICK/ Japan OMRON

7, temperature control components: Japan OMRON

8, PLC: SIEMENS
